Available 8 Ohm and 16 Ohm
Nominal Specifications
| Throat Diameter | 25,4 mm (1 in) |
| Overall Diameter | 121 mm (4.76 in) |
| 180° Mounting Holes Diameter (2xM6) | 76 mm (2.99 in) |
| Depth | 55 mm (2.17 in) |
| Net Weight | 2.2 kg (4.9 lb) |
| Shipping Box (Single carton box) |
185 x 170 x 102 mm (7.3 x 6.7 x 4.0 in) |
| Shipping Weight | 2.5 kg (5.5 lb) |
Technical Parameters
| Nominal Impedance | 8 Ohm |
| Minimum Impedance | 6.8 Ohm |
| AES Power Handling (1) | 60 W |
| Maximum Power Handling (2) | 120 W |
| Minimum Crossover Frequency (3) | 1.3 kHz |
| Sensitivity (1W/1m) (4) | 108 dB |
| Frequency Range | 1÷20 kHz |
| Voice Coil Diameter | 44 mm (1.73 in) |
| Winding Material | Al |
| Former Material | Kapton |
| Diaphragm Material | Ketone Polymer |
| Diaphragm Shape | Dome |
| Winding Depth | 2.3 mm (0.09 in) |
| Magnetic Gap Depth | 2.85 mm (0.11 in) |
| Flux Density | 1.8 T |
| Magnet | Ferrite Ring |
| Re | 5.8 Ohm |
| Phase Plug Design | Annular |
| Exit Angle (5) | 13° Conical |
| NET Air Volume filled by HF Driver | 0.43 dm^3 (0.015 ft^3) |
