550W Long Life Discharge IP65 Beam with CMY

FEATURES

Powerful 0.8° Beam Angle
3.5° Beam Expander
CMY Color Mix
Dual overlapping prisms
Ultra-wide 260mm / 10" Front Lens
IP65 rating protects from water and dirt
4,000h Long Life 550W Lamp

Sky Motion System for powerful searchlight and skytracker animations

SOURCE

Philips MSD Platinum 500L Flex 550W Lamp
Variable Lamp Power
Automated Lamp Hibernation with Instant Recovery
Up to 4,000 Hour Lamp Life*
*Lamp Life may vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control and Dimming.

PHOTOMETRIC DATA

0.8° Beam Angle
1.6° Field Angle
3.5° Beam Expander Lens
20,000 Total Lumen Output
7,000K CRI 77+
335,000 LUX @ 15m
7,500 LUX @ 100m

EFFECTS

Beam Expander
Focus
Dual Rotating Prisms and Prism Macros
Dual Frost Filter Hybrid Wash Effect
High Speed Mechanical Shutter and StrobePan Angle: 540°/630°
Tilt Angle: 250°

COLOR

14 Dichroic Colors Including CTO and UV
Full CMY Color Mixing

GOBOS

8 Interchangeable Rotating / Indexing Glass Gobos
17 Static-Stamped Metal Gobos

CONTROL / CONNECTIONS

Single DMX Mode (26ch.)Sky Motion Standalone mode for searchlight and skytracker animations
16-bit Pan, Tilt, and Dimming Control
Motorized Focus
DMX, RDM, Art-NET, and sACN Protocol Support
6 Button Touch Control Panel
Full Color 180° Reversible LCD Menu Display
Hibernation Mode (Power Save)
IP65 5pin DMX In/Out
IP65 RJ45 ethernet In/Out
Locking IP65 Power In

SIZE / WEIGHT

Length: 493mm (19.4 in)
Width: 383mm (15.1 in)
Vertical Height: 697mm (27.4 in)Center Spacing: 592.8mm (23.3")
Weight: 49kg (108lbs)

ELECTRICAL / THERMAL

AC 100-240V - 50/60Hz
800W Max Power Consumption
-20°C to 45°C (-4°F to 113°F)
