DAS Audio WR-8826-CX pasīvā skanda

€919,00

Tax included. Shipping calculated at checkout

Select quantity

Performance
Frequency Range (-10 dB)	70 Hz – 22 kHz
Horizontal Coverage (-6 dB)	80º
Vertical Coverage	80º
Nominal Impedance	16 ohms
RMS Power Handling	200 W
Peak Power Handling	800 W
On-axis Sensitivity 1W/1 m	93 dB SPL
Maximum Peak SPL at 1 m	122 dB
Recommended Amplifier	INTEGRAL-A402 INTEGRAL-A404 INTEGRAL-A1002 INTEGRAL-A1004 INTEGRAL-A1602 INTEGRAL-A1604 INTEGRAL-MA1004 INTEGRAL-MA1604
Recommended Processor	INTEGRAL-M88 INTEGRAL-MA1604 INTEGRAL-MA1004

Connectors
Audio Input Connector	Covered Barrier Strip Terminals
Audio Output Connector	Covered Barrier Strip Terminals
Enclosure
Enclosure Construction	Birch Plywood
Enclosure Geometry	Trapezoidal
Rigging	M10 Rigging Points
Finish	ISO-flex Paint
Color	Black
IP Rating	IP56
Depth	270 mm (10,6 in)
Dimensions ( H x W x D )	550 x 230 x 270 mm 21,7 x 9,1 x 10,6 in
Net Weight	11,0 kg ( 24,5 lb )
Components
LF Driver	6B
HF Driver	M-1
Horn/Waveguide	BC-88
Shipping
Carton Dimensions ( H x W x D )	608 x 274 x 345 mm 23,9 x 10,8 x 13,6 in
Shipping Weight	15,0 kg ( 33,0 lb )

€919,00
