Nominal Specifications
| Nominal Diameter | 250 mm (10 in) |
| Overall Diameter | 260 mm (10.24 in) |
| Bolt Circle Diameter | 246 mm (9.69 in) |
| Baffle Cutout Diameter | 233 mm (9.17 in) |
| Depth | 110 mm (4.33 in) |
| Flange and Gasket Thickness | 7 mm (0.28 in) |
| Net Weight | 3.47 kg (7.7 lb) |
| Shipping Box (Single Carton Box) |
282 x 280 x 155 mm (11.1 x 11.0 x 6.10 in) |
| Shipping Weight | 4.0 kg (8.8 lb) |
Technical Parameters
| Nominal Impedance | 8 Ohm |
| Minimum Impedance | 6.1 Ohm |
| AES Power Handling (1) | 250 W |
| Maximum Power Handling (2) | 500 W |
| Sensitivity (1W/1m) | 92 dB |
| Frequency Range | 35÷4000 Hz |
| Voice Coil Diameter | 52 mm (2.05 in) |
| Winding Material | Al |
| Former Material | Glass Fiber |
| Winding Depth | 19.3 mm (0.76 in) |
| Magnetic Gap Depth | 8 mm (0.31 in) |
| Flux Density | 1.1 T |
| Magnet | Ferrite Ring |
| Basket Material | Steel |
| Demodulation | No |
| Cone Surround (3) | Half Roll |
| NET Air Volume filled by Loudspeaker | 1.4 dm^3 (0.049 ft^3) |
| Spider Profile | 1x variable height waves |
Thiele and small parameters
| Fs | 35 Hz |
| Re | 5.3 Ohm |
| Qes | 0.43 |
| Qms | 6.7 |
| Qts | 0.40 |
| Vas | 72.4 dm^3 (2.56 ft^3) |
| Sd | 382 cm^2 (59.21 in^2) |
| Xmax (4) | 8.32 mm |
| Xdamage (5) | 13.6 mm |
| Mms | 58.2 g |
| Bl | 12.6 N/A |
| Le | 1.1 mH |
| Mmd | 49.8 g |
| Cms | 0.36 mm/N |
| Rms | 1.9 kg/s |
| Eta Zero | 0.70 % |
| EBP | 82 Hz |
