Incorporating two 7-inch woofers, a midrange driver, and ADAM Audio’s X-ART tweeter, the A77H delivers an ultra-wide frequency range. The addition of the midrange driver helps produce clear sound in the most sensitive range of human hearing. Rotatable HPS waveguide technology and onboard DSP allow you to tune the sound for your precise requirements.
- Drivers: 2x 7" MLM woofer, 1x 3.5" MLM midrange driver, rotatable X- ART tweeter + HPS waveguide
- Amplifier power RMS: 250 W (woofer) + 70 W (midrange) 20 W (tweeter)
- Crossover frequency: 400 Hz, 3 kHz
- Maximum power consumption: 500 W
- Integrated AD-converter 24-bit / 96 kHz
- 4-Band equaliser with "Bass", "Desk", "Presence" and "Treble" parameters to adapt to room acoustics
- Voicings function with preset sound profiles
- Real-time control of DSP-based functions via ethernet
- Control Remote software allows filter models to be loaded into the monitor's own DSP
- Sonarworks integration (Sonarworks software and measurement microphone not included)
- AC input voltage: 100 - 240 V, 50/60 Hz
- 1 Line input: XLR balanced
- 1 Line input: RCA
- 1 Ethernet connection
- Dimensions (H x W x D): 236 x 531 x 350 mm
- Weight: 17.1 kg
