| Performance | |
| Frequency Range (-10 dB) | 40 Hz – 125 Hz |
| Maximum Peak SPL at 1 m | 131 dB |
| Electronics and Connectors | |
| Nominal Amplifier Power (continuous) | 600 W |
| Nominal Amplifier Power (peak) | 1200 W |
| Input Type | Balanced |
| Input Impeadance | 20 kohms |
| Input Sensitivity | 1.95 V (+8 dBu) |
| Audio Signal Input Connector | 2 x Female XLR |
| Audio Signal Loop Thru Connector | 2 x Male XLR |
| Control | DAScontrol™ |
| AC Output Connector | powerCON NAC3MPB |
| Current Draw 230 V / 115 V | 1.4 A/2.8 A |
| Enclosure | |
| Enclosure Construction | Birch Plywood |
| Enclosure Geometry | Rectangular |
| Finish | ISO-flex Paint |
| Color | Black |
| Dimensions ( H x W x D ) | 470 x 485 x 685 mm 18,5 x 19,1 x 27,0 in |
| Net Weight | 30,0 kg ( 66,0 lb ) |
| Components | |
| LF Driver | 15FW4 |
| Shipping | |
| Carton Dimensions ( H x W x D ) | 515 x 525 x 716 mm 20,3 x 20,7 x 28,2 in |
| Shipping Weight | 35,0 kg ( 77,0 lb ) |
