Two-channel Class-D amplifier with 2 × 240 W power outputs. Designed for 100 V and low-impedance high-quality background music systems.
It can be bridged in 100V mode to use as a single channel 480 W amplifier for 100V audio systems. With silent fan mode and DSP processing, including 6-point parametric EQ, limiter, gate, and delay. Equipped with balanced Phoenix and stereo RCA inputs and audio link output connectors. The amplifier has an RS232 control port for integration with third-party control systems, allowing iAC amplifiers to be used in large and complex audio systems that can be automated and controlled remotely.
Output power: 2 x 240 W @ 100 V, 2 x 240 W @ 4 Ω
Bridged output power: 1 x 480 W @ 4 Ω
Outputs: 2 x Phoenix power output, 2 x Phoenix audio link
Inputs: 2 x Balanced Phoenix, 2 x Stereo RCA
Frequency response: 35 Hz - 21 kHz
THD: 0,16 %
S/N ratio: 94 dB
Dimensions: 88 mm x 430 mm x 342 mm
