380W Cool White LED Framing Profile Fixture
FEATURES
High Efficiency 380W White LED Engine, 91CRI
Dual Color Wheel (Solids and Color Corrections)
Rotating Gobo Wheel
Full Blackout Framing System
Iris and Frost
Wide Zoom Range from 9° to 43°
SOURCE
380W 6,000K White LED Engine
30,000 Hour Average LED Life*
*Lamp Life may vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control and Dimming.
PHOTOMETRIC DATA
11,200 Total Lumen Output
CRI 91
Zoom Range 9° - 43°
Beam Angle 9.3° - 43.1°
Field Angle 10.3° - 46.8°
EFFECTS
Motorized Zoom
4 Rotating Full Blackout Framing Blades, +/- 60° Index
Variable Frost Filter
Motorized Iris
Variable 16-bit Dimming Curve Modes
High Speed Electronic Shutter and Strobe
Adjustable LED Refresh Rate Frequency
Pan Angle: 540°/630°
Tilt Angle: 270°
COLOR
2 Color Wheels
7 Solid Colors
7 Color Corrections and UV
GOBOS
1 Gobo Wheel
7 Rotating / Indexing Interchangeable Glass Gobos
CONTROL / CONNECTIONS
2 DMX Channel Modes (26 / 40)
16-bit Pan, Tilt, and Dimming Control
Motorized Focus
DMX, RDM Protocol Support
4 Button Touch Control Panel
Full Color 180° Reversible LCD Menu Display
16 Bit Resolution Adjustable Movement
Hibernation Mode (Power Save)
5pin DMX In/Out
IP65 Locking Power Cable In/Out
With Wired Digital Communication Network
SIZE / WEIGHT
Length: 408mm (15.9”)
Width: 252mm (9.9”)
Vertical Height: 698mm (27.4”)
Weight: 23.3kg (51.4 lbs.)
ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
590W Max Power Consumption
-10°C to 45°C (14°F to 113°F)
BTU/hr (+/- 10%) 2011.9
