| Performance | |
| Frequency Range (-10 dB) | 28 Hz – 125 Hz |
| Nominal Impedance | 4 ohms |
| RMS Power Handling | 2200 W |
| Peak Power Handling | 8800 W |
| On-axis Sensitivity 1W/1 m | 103 dB SPL |
| Maximum Peak SPL at 1 m | 143 dB |
| Recommended Amplifier | DX-100-230 DX-100-115 |
| Recommended Processor | DSP-4080 |
| Connectors | |
| Audio Input Connector | 2 x speakON NL4 |
| Audio Output Connector | 2 x speakON NL4 |
| Enclosure | |
| Enclosure Construction | Birch Plywood |
| Enclosure Geometry | Rectangular |
| Rigging | M10 Rigging Points |
| Finish | ISO-flex Paint |
| Color | Black |
| Depth | 1.005 mm (39,6 in) |
| Dimensions ( H x W x D ) | 515 x 955 x 1.005 mm 20,3 x 37,6 x 39,6 in |
| Net Weight | 87,5 kg ( 192,9 lb ) |
| Components | |
| LF Driver | 18UXN |
| Shipping | |
| Carton Dimensions ( H x W x D ) | 560 x 1.020 x 1.055 mm 22,0 x 40,2 x 41,5 in |
| Shipping Weight | 96,0 kg ( 211,6 lb ) |
