FEATURES

220W RGBMA LED Engine
Dynamic White + Full Spectrum Color Control
7,200 Total Fixture Lumen Output
10° to 32° Wide Manual Zoom
Stand-Alone control with Encoder and LED Display
Smooth 16-bit Selectable Dimming Modes and Curves
LED Refresh Rate Adjustment
Flicker Free Operation for TV and FILM
RDM (Remote Device Management)
Pole-Operated Pan, Tilt and Zoom control
8-leaf Barn Doors, Gel Frame and Junior Pin (1 1/8” - 28mm) included

SPECIFICATIONS

SOURCE

220W 6500K RGBMA LED Engine
50,000 Hour Average LED Life*
*May vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control and Dimming

PHOTOMETRIC DATA

7,200 Total Lumen Output
CRI 92.5
Zoom Range 10° - 32°
Beam Angle 9.7° - 32.2°
Field Angle 18.7° - 49.3°

EFFECTS

Pole-Operated Pan, Tilt, Zoom
Electronic Dimmer and Strobe
Variable 16-bit Dimming Modes and Curves

COLOR

RGBMA Color Array
CMY Emulation
Variable CCT 2400K - 8500K
Green/Magenta Shift
Virtual Gel Swatch Book

CONTROL / CONNECTIONS

6 DMX Channel Modes (1 to 18 channels)
Direct Access Encoder
4 Button Control Panel, LED Display
RDM (Remote Device Management)
3/5pin DMX and IP65 Locking Power In/Out Connection

SIZE / WEIGHT

Length: 344mm (13.5”)
Width: 280.6mm (11”)
Vertical Height:584mm (23”)
Weight: 8.4kg (18.5 lbs.)

ELECTRICAL / THERMAL

AC 100-240V - 50/60Hz
219W Max Power Consumption
-15°C to 45°C (5°F to 113°F)
BTU/hr (+/- 10%) 687.66

INCLUDED ITEMS

Gel Frame and Rotating 8-leaf Barn Doors
Junior Pin (28mm - 1 1/8”)
IP65 Locking Power Cable

FIRMWARE UPDATES

Current firmware can be found here (login required)
