500W Solid State phosphor-converted Beam FX Fixture.

Command the heavens with Elation’s PROTEUS ATLAS, built to deliver otherworldly light for large-scale productions and permanent outdoor installations. With 1 million LUX at 20 meters, LILI technology, and a massive 320mm lens, Atlas cuts through the sky with bold, focused beams that evoke the power of traditional Xenon fixtures.

Its onboard effects system sculpts light with gobos, frosts, and prisms—shifting seamlessly from piercing beams to layered textures and soft washes. With CMY color mixing and a 25-position color wheel, Atlas offers a rich palette for bold bursts, atmospheric moods, and everything in between.

The Atlas’ precision motors provide smooth pan, tilt, and continuous rotation, while Elation’s SkyMotion system enables synchronized patterns across fixtures without a console. Built and certified with an IP66 rating, Atlas stands strong in any weather, making it ideal for concerts, cruise ships, and permanent outdoor installs.

Designed for those who think on a larger scale, PROTEUS ATLAS delivers power, precision, and creative freedom, letting audiences look up and experience the extraordinary.

FEATURES

500W LILI (Laser Illuminated Lighting Instrument)
IP66 housing
Ultra Long Throw Beam FX
Continuous 360 Pan Movement
CMY Color Mixing
FX Package with rotating, fixed gobos, prisms and dual frost
Sky Motion Standalone System
Protective Foam In Lay for transport

SOURCE

500W LILI (Laser Illuminated Lighting Instrument)
9000K, CRI 70
12,000 Hour Lamp Life

*Lamp Life may vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control and Dimming.

PHOTOMETRIC DATA

1.000.000 Lux @ 20m
100.000 Lux @ 100m
Beam Angle 0.6° - 8.5°

EFFECTS

Dual Frost (Hot- Spot Beam, Wash FX)
Ultra- Fast Zoom
Focus
2x3 Prisms on Dual Planes
Digital Shutter and Strobe
Pan Angle 360° / 540°
Tilt Angle 250°

COLOR

Full CMY Color Mixing System
25 Position Color Wheel

GOBOS

2 Gobo Wheels
13 Interchangeable-Rotating / Indexing Metal Gobos
26 Static-Stamped Metal Gobos

CONTROL / CONNECTIONS

2 DMX Channel Modes (26/36 Ch)
(6) Button Touch Panel
Full Color 180° Reversible LCD Menu Display
DMX, RDM, Art-Net and sACN Protocol Support
NFC Support
Ip65 5pin DMX In/Out
IP65 RJ45 Ethernet In/Out
IP65 Locking Power In

SIZE / WEIGHT

Length: 370mm (14.5")
Width: 508mm (20")
Height: 800mm (31.5")
Weight: 56.3 kg (124.1lbs.)

ELECTRICAL / THERMAL

AC 100-240V - 50/60Hz
670W Max Power Consumption
-20°C to 45°C (-4°F to 113°F)
