Nominal Specifications
| Nominal Diameter | 250 mm (10 in) |
| Overall Diameter | 260 mm (10.24 in) |
| Bolt Circle Diameter | 246 mm (9.69 in) |
| Baffle Cutout Diameter | 233 mm (9.17 in) |
| Depth | 111 mm (4.37 in) |
| Flange and Gasket Thickness | 7 mm (0.28 in) |
| Net Weight | 2.95 kg (6.5 lb) |
| Shipping Box (Single Carton Box) |
285 x 285 x 165 mm (11.2 x 11.2 x 6.49 in) |
| Shipping Weight | 3.5 kg (7.7 lb) |
Technical Parameters
| Nominal Impedance | 8 Ohm |
| Minimum Impedance | 6 Ohm |
| AES Power Handling (1) | 200 W |
| Maximum Power Handling (2) | 400 W |
| Sensitivity (1W/1m) | 96 dB |
| Frequency Range | 60÷4500 Hz |
| Voice Coil Diameter | 44 mm (1.73 in) |
| Winding Material | Al |
| Former Material | Al |
| Winding Depth | 13.5 mm (0.53 in) |
| Magnetic Gap Depth | 8 mm (0.31 in) |
| Flux Density | 1.10 T |
| Magnet | Ferrite Ring |
| Basket Material | Steel |
| Demodulation | No |
| Cone Surround (3) | Triple Roll |
| NET Air Volume filled by Loudspeaker | 1.25 dm^3 (0.044 ft^3) |
| Spider Profile | 1x constant height waves |
Thiele and small parameters
| Fs | 60 Hz |
| Re | 5 Ohm |
| Qes | 0.52 |
| Qms | 5.2 |
| Qts | 0.47 |
| Vas | 35.3 dm^3 (1.25 ft^3) |
| Sd | 362 cm^2 (56.11 in^2) |
| Xmax (4) | 5.42 mm |
| Xdamage (5) | 14.9 mm |
| Mms | 36.5 g |
| Bl | 11.5 N/A |
| Le | 0.68 mH |
| Mmd | 28.7 g |
| Cms | 0.19 mm/N |
| Rms | 2.7 kg/s |
| Eta Zero | 1.42 % |
| EBP | 115 Hz |
