Specifications in detail
Mic inputs
- Frequency Response 20-20kHz:± < 0.03dB
- Frequency Response 20-35kHz:± < 0.15dB
- Dynamic Range (min gain):118dB
- THD+N (-1dBFS, +20dB gain):-110dB
- Noise EIN:-129dBu
- Max input level:18dBu
- Gain range:+57dB
Instrument inputs
- Frequency Response 20-20kHz:± < 0.04dB
- Frequency Response 20-35kHz:± < 0.15dB
- Dynamic Range:116dB
- THD+N (-1dBFS, min gain):-96.5dB
- Max input level:15dBu
- Gain range:+57dB
Line inputs (variable)
- Frequency Response 20-20kHz:± < 0.05dB
- Frequency Response 20-35kHz:± < 0.15dB
- Dynamic Range (min gain):118dB
- THD+N (-1dBFS, min gain):-100dB
- Max input level:26dBu
- Gain range:+57dB
Line & monitor outputs
- Frequency Response 20-20kHz:± < 0.02dB
- Frequency Response 20-35kHz:± < 0.02dB
- Dynamic Range:124dB
- Max Output level:18dBu
- THD+N:-106dB
Line inputs (fixed)
- Frequency Response 20-20kHz:± < 0.05dB
- Frequency Response 20-35kHz:± < 0.15dB
- Dynamic Range:118dB
- THD+N (-1dBFS):-100dB
- Max input level:+18dBu
Headphone outputs
- Frequency Response 20-20kHz:<0.06dB
- Frequency Response 20-35kHz:<0.07dB
- Dynamic Range:118dB
- THD+N:-104dB
- Max Output level:16dBu
