Specifications in detail

Mic inputs

• Frequency Response 20 - 20kHz:± < 0.03dB
• Frequency Response 20 - 35kHz:± < 0.15dB
• Dynamic Range (min gain):118dB
• THD+N (-1dBFS, +20dB gain):-110dB
• Noise EIN:-129dBu
• Max Input Level:18dBu
• Gain Range:+57dB

Line inputs

• Frequency Response 20 - 20kHz:± < 0.05dB
• Frequency Response 20 - 35kHz:± < 0.15dB
• Dynamic Range (min gain):118dB
• THD+N (-1dBFS, min gain):-100dB
• Max Input Level:26dBu
• Gain Range:+57dB

Instrument inputs

• Frequency Response 20 - 20kHz:± < 0.04dB
• Frequency Response 20 - 35kHz:± < 0.15dB
• Dynamic Range:116dB
• THD+N (-1dBFS, min gain):-96.5dB
• Max Input Level:15dBu
• Gain Range:+57dB

Line outputs

• Frequency Response 20 - 20kHz:± < 0.02dB
• Frequency Response 20 - 35kHz:± < 0.02dB
• Dynamic Range:124dB
• Max Output Level:18dBu
• THD+N:-106dB
